dnp开发出新型的框架系统，可用于电视演播室、会议室和控制室中配备大屏幕的多屏应用。该框架系统专为现场组装而设计，以有效降低成本，减少困扰。
更大的显示系统意味着屏幕之间的接缝更少，所需的投影机更少，维修成本更低……选择用大屏幕的显示墙代替大量箱体的原因有很多。然而，由于显示屏幕尺寸较大，在多屏幕应用场合，若要安装2个、3个或4个大型光学屏幕以及框架系统，也是极具挑战性的事情。
解决方案之一就是使用dnp的ViewFlex系统，因为在屏幕出厂时就已被预先框架组装。但是，显而易见，大型多屏幕结构的运输和现场安装既昂贵又困难。
为了解决此类物流难题，dnp现为大型屏幕设计了一个崭新的框架系统，可让客户单独运输屏幕，并且可直接在安装地点进行组装。这项崭新的框架系统允许屏幕水平并排尺寸由67” 到 200”的所有dnp单层屏幕。
此系统在屏幕边缘处1mm的小孔中穿入细线接缝，使得每张屏幕能被巧妙地结合在一起，屏幕的物理拼缝为零，光学图象间隙仅为2mm。接缝后方的遮光板避免了投影机投出的光线映在相邻的屏幕上。屏幕固定于框架的顶部，这样即使当温度和湿度发生变化时，屏幕也可以得到伸展而不会弯曲。
如需了解更多技术规格和其它信息，请浏览
www.dnp.dk
或联系当地dnp经销商。
New frame system for large screen walls
dnp has developed a new frame system for multi-screen applications with large screens in TV studios, conference rooms and control rooms. The frame system is designed for on-site assembly to reduce costs and hassle.
Larger displays with less seams, fewer projectors and lower maintenance costs… The reasons for using large screens in display walls in stead of a large number of cubes are many. But installation and framing of
multi-screen applications with two, three or four large optical screens can also be quite a challenge due to the huge display sizes.
A way to get around this is to use dnp´s ViewFlex system where several screens are delivered pre-framed from the factory. But it goes without saying, that transportation and on-site handling of a huge multi-screen structure can be both costly and difficult.
To solve these logistical problems, dnp now launches a framing system for large screens that allows individual transportation of screens and assembly directly at the installation site. The new system allows horizontal side-by-side framing of all dnp single-element screens in sizes from 67” to 200”.
A system of stitches of thin wire through 1mm holes at the edge of the screen keeps the screen elements neatly together with an image gap of only 2mm. Baffles behind the seams prevent light from the projectors from hitting neighbouring screens. And the screens are fixed at the top of the frame to allow expansion without bending due to changes in temperature and humidity
For more details and technical specifications see
www.dnp.dk or contact your local dnp distributor.
|
